AE-600EQ Specification

System

Operating Frequency: UHF

Modulation: FM

Frequency Stability: ±0.005%

Signal-to-Noise Ratio: ≥105 dB

Dynamic Range: ≥90 dB

Total Harmonic Distortion: ≤0.5% @1 kHz

Receiver

Receiving Mode: Dual-channel independent

Diversity: True Diversity (dual antennas)

Sensitivity: –95 dBm

Outputs:

Balanced XLR × 2

Unbalanced 6.35 mm × 1

Display: Channel / Frequency / RF / AF / Battery

Power Supply: AC input

Housing: Metal 1U rackmount

Handheld Transmitter

Mic Type: Dynamic

Polar Pattern: Cardioid

Frequency Response: 50 Hz – 18 kHz

Sensitivity: –45 dB ±2 dB

RF Output Power: 10–30 mW

EQ Function: Adjustable High / Mid / Low

Display: Channel, Frequency, Battery, EQ

Battery: 2 × AA
