SYSTEM PARAMETERS:

•Frequency range: (standard version) 560-680MHZ (band width 120MHZ)

•Number of channels: (standard version) 400, (US version) 200

•Effective distance: more than 300 meters

•Channel spacing: 300KHZ

•S/N ratio: >90DB

•Shipping weight: 3.37KG

•Receiver size: 480×178×45mm (lengthwidth depth)

RECEIVER TECHNICAL PARAMETERS:

•Frequency error: ±10KHZ

•Frequency oscillation mode: PLL phase-locked frequency synthesis

•Receiving mode: pure digital DOPSK modulation and digital encryption ID

•Bandwidth: 200MHZ

•Dynamic range: >90DB

•Distortion: <0.1%

•Frequency response range: 30-20KHZ

•Receiving sensitivity: 5DBUV

•Display mode: 2.4-inch TFT

•Power supply: 12V/DC 1A

•Audio output: 2×XLR (balanced) 1×TS6.35mm (unbalanced)

TRANSMITTER TECHNICAL PARAMETERS:

•Frequency oscillation mode: PLL phase-locked frequency synthesis

•Transmitting power: <10MW

•Transmitting mode: pure digital DOPSK adjustment and digital encryption ID

•Frequency error: ±10KHZ

•Display mode: 0.96-inch TFT

•Frequency switching: infrared synchronization

•Pick up type: dynamic type

•Power supply: 2 AA1.5V5 batteries

•Working time: more than 10 hours
