Technical Parameters:



Frequency Range: 645-685MHz

Working Distance: 150 meters

Signal-to-noise Ratio: ≥110dB

Tunable Channel: 80x2



Oscillation Mode: PLLFrequency Stability: ±10ppm

Modulation Mode: FM

Pilot Way: Digital pilot

Receiving Sensitivity: -95~-67dBm

Frequency Response: 40HZ-18KHZ

Total Harmonic distortion: ≤0.5%

Receive Mode: Superheterodyne secondary frequency conversion

Transmitted Power: 3-30mW

Audio Output: Balance output and mixed output

Battery Specifications: 2* 1.5V（AA）

Power supply: DC 12V

Power Consumption: ≤10W



Function Description:



*PLL dual-channel digital frequency lock technology

*Automatic scanning and locking of 160 UHF frequency point

*Interference resistance design for multi-channel use

*Intelligent hand sensing, auto mute, smart stay

*Lockable control function button

*150 meters long distance reception

*Monitor function
