System

Oscillation mode: PLL synthesized

Frequency range: 530-950MHz

Modulation: FM

Max.deviation: ±48KHz

Audio frequency: 50Hz-15KHz

T.H.D: ≤1%

Working Temperature: 0?~+40?

Receiver

Sensitivity: 7dBuV(>78dB)

Sensitivity range: 30dBuV

RF squelch?≥75dB

Audio output level?Balanced output: -20dBV/100Ω; MIC output: -12dBV/5KΩ

Power: DC12

Working power: 1000mA

Transmitter

RF output power: 10mW

RF squelch: -55dB

Battery: 1.5Vx2 purchase

Pick-up pattern: Dynamic
