Frequency range: 610-960MHz (depend on applicable country regulations)

Channel: 200 preseeting frequencies

Modulation: Wide band FM

Max Deviation: ±45KHz

Frequency response: 50Hz-15 KHz

S/N. :> 105dB (A)

T.H.D. (1 KHz): <0.3%

Operational Temperature: -10℃-55℃

Working Range: 80M (in ideal environment)

Receiver

Oscillation mode: PLL (Digital frequency synthesizer)

F/N Ratio: ≥80dB

P/N Ratio: ≥80dB

Sensitivity: 5dBuV

Audio output Voltage: Balanced (XLR jack): 250mV/600Ω

Unbalanced (1/4 jack): 400mV/3KΩ

Working Voltage: DC 13.5-16V

Working current: ≤800mA

Handheld transmitter

RF output power: 30mW (depend on applicable country regulations)

Oscillation mode: PLL (digital frequency synthesizer)

Stability: <30ppm

Dynamic range: ≥100dB (A)

Frequency response: 50Hz-15 KHz

Max input sound pressure: 130dB SPL

Mic capsule: dynamic

Power supply: AA alkaline batteries
