Receiver

Frequency Preparation: PLL Synthesized Control

Carrier Frequency Range: 520MHz~952MHz

S/N Ratio: >75dB

T.H.D: <1%

Display: LCD

Display Contents: Channel, Antenna A/B, Mute Display, RF/AF, Level Meter,Battery Fuel Gauge,ID Number

Controls: Power On/Off, Frequency Up/Down, Audio Level, Lock-on, ID Pairing, Remoset

Audio Output Level: -12dB

AF Output Impedance: 600Ω

Squelch: Pilot Tone & Noise Mute

Operation Voltage: 12-17VDC, 600 mA

Output Connector: 1 XLR Balanced Socket

1 φ6.3mm Unbalanced phone jack

Dimension(m/m): 80mm(W) 44mm(H) 213mm(D)

Transmitter

Frequency Preparation: PLL Synthesized Control

Carrier Frequency Range: 500MHz~870MHz

RF Outputs: 5-50mW

Stability: ±0.005%

Frequency Deviation: ±48kHz

LCD Display: Channel, Battery Fuel Gauge, ID Number Controls Power On/Off, AF Level, Frequency Up/Down, Lock-on Mode, ID Pairing

Spurious Emissions: <-60 dBC

Audio Frequency Response: 50Hz~18KHz

Battery: AA 1.5V*2
