Overview:

Using DSP to process the microphone signal, easy adjustment, even if no tuning

experience can also obtain a good sound effect. Through the exclusive algorithm, make

the song more beautiful, the voice more plump. With anti-howling function, even in the ordinary environment can also rest assured to sing.

Characteristics:

Real DSP digital signal processing

24 for BIT / 48K signal conversion

Excellent reverberb effect

It combines reverberation (Reverb) and echo (Echo) effects

The parameters are easily adjustable

Three-level intensity anti-noise call function

Multiple types of signal inputs

the parameter Specifications

Music channel Music

noise-signal ratio S/N >95dB @ 1KHz,+10dB V ,AUDIO Weight

Frequency response to Response 20Hz -20KHz ,+/-1dB

degree of distortion THD <0.01% @ 1KHz, +10dBV

Maximum input level of Max Input Le vel +6dBV

Bass tuning of the Bass E Q +/-10dB @ 100Hz

Middle-tone tuning of the Mid EQ +/-10dB @ 1KHz

The high pitch regulates the Treble EQ +/-10dB @ 10KHz

Microphone channel

noise-signal ratio S/N >85dB @ 1KHz,+10d BV ,AUDIO Weighted

Frequency response to Response 40Hz-15KHz,+1/-3dB

degree of distortion THD <0.1% @ 1KHz, +10d BV

Maximum input level of Max Input Le vel -14dBV

Bass tuning of the Bass E Q +/-6dB @ 100Hz

Middle-tone tuning of the Mid EQ +/-6dB @ 1KHz

The high pitch regulates the Treble EQ +/-6dB @ 10KHz
