AE-600EQ Wireless Microphone System Wholesale

PROFESSIONAL AUDIO · B2B SOURCING

AE-600EQ for Professional Buyers

AE-600EQ is a dual-channel digital wireless microphone system with encrypted ID, infrared synchronization, TFT displays and published long-range operation beyond 300 m.

REQUEST WHOLESALE PRICE

Why Buyers Consider the AE-600EQ

Clear sourcing profile: key RF, audio and power data are consolidated for comparison.
Application flexibility: suitable for professional audio, education, events and installation channels.
Regional ordering: exact operating band must be legal in the destination market.
Order verification: confirm transmitter type, included accessories, connector and carton details before purchase.

Product Overview

AE-600EQ is a dual-channel digital wireless microphone system with encrypted ID, infrared synchronization, TFT displays and published long-range operation beyond 300 m.

Published Specifications

Channels	2
Frequency range	560–680 MHz standard version
Channel count	400 standard / 200 US stated
Channel spacing	300 kHz
Published distance	>300 m
S/N ratio	>90 dB
Dynamic range	>90 dB
THD	<0.1%
Frequency response	30 Hz–20 kHz
Receiver display	2.4-inch TFT
Receiver power	12 V DC / 1 A
Outputs	2 × balanced XLR; 1 × unbalanced 6.35 mm
Sync	Infrared
Microphone	Dynamic
Transmitter power	<10 mW
Battery	2 × AA; >10 h stated
Shipping weight	3.37 kg
Receiver size	480 × 178 × 45 mm
Compliance	Confirm frequency legality for destination market
Package / MOQ	Request confirmation

Applications and Buyer Fit

Suitable for venues, stages, houses of worship, rental companies and professional-audio integrators.

ASK ABOUT DISTRIBUTOR TERMS →

Wholesale and Project Support

Contact ELEGAUDIO for pricing, quantities, availability, packing details and project requirements. Include destination market, quantity and intended application.

Frequently Asked Questions

Is the AE-600EQ available for wholesale orders?
Yes. Contact ELEGAUDIO with your quantity, destination market and application for current pricing and availability.

Can specifications or packaging be confirmed before ordering?
Yes. Request the current specification sheet, packing information and order details before purchase.

What information should I include in an inquiry?
Please include model, quantity, destination country and intended application for a faster quotation.

Source the AE-600EQ for Your Market

Request current pricing, availability and distributor support.

GET A QUOTE

SYSTEM PARAMETERS: •Frequency range: (standard version) 560-680MHZ (band width 120MHZ) •Number of channels: (standard version) 400, (US version) 200 •Effective distance: more than 300 meters •Channel spacing: 300KHZ •S/N ratio: >90DB •Shipping weight: 3.37KG •Receiver size: 480×178×45mm (lengthwidth depth) RECEIVER TECHNICAL PARAMETERS: •Frequency error: ±10KHZ •Frequency oscillation mode: PLL phase-locked frequency synthesis •Receiving mode: pure digital DOPSK modulation and digital encryption ID •Bandwidth: 200MHZ •Dynamic range: >90DB •Distortion: <0.1% •Frequency response range: 30-20KHZ •Receiving sensitivity: 5DBUV •Display mode: 2.4-inch TFT •Power supply: 12V/DC 1A •Audio output: 2×XLR (balanced) 1×TS6.35mm (unbalanced) TRANSMITTER TECHNICAL PARAMETERS: •Frequency oscillation mode: PLL phase-locked frequency synthesis •Transmitting power: <10MW •Transmitting mode: pure digital DOPSK adjustment and digital encryption ID •Frequency error: ±10KHZ •Display mode: 0.96-inch TFT •Frequency switching: infrared synchronization •Pick up type: dynamic type •Power supply: 2 AA1.5V5 batteries •Working time: more than 10 hours

AE-600EQ 2-Channel Wireless Microphone System
