Product Description
Main features:
1. 8-channel mono input, high-quality microphone amplifier
2. 3-band frequency input
3. High-precision 2-channel level display
4. 60mm high analysis and durable fader
5. Built-in professional digital effects processor
6. Microphone output monitoring
7. Recording output
8. USB input, stereo output
Technical Parameters:
▲Maximum output level: 19dBm (1KHz, THD=0.5%)
▲Residual noise: -105dB
▲Signal to noise ratio: ≤ 80dB
▲Equivalent noise source input electromotive force: -115dBm
▲Headphone output power: 100mw (1KHz, THD=0.5%, 200Ω)
▲Equalization: Low frequency: 80Hz ±15dB
Intermediate frequency: 2.5KHz±15dB
High frequency: 12KHz ±15dB
▲Gain control: mono -60dB~-40dB
▲Frequency response: 20Hz~20KHz(±3dB)
▲Total harmonic distortion + noise: ≤0.003% (1KHz, 0.775V)
