Transmitter Specifications * Chassis: Standard 1U * Frequency Range: 550–590MHz / 640–690MHz * Audio Sampling: 24bit / 44.1kHz (latency ≤ 0.3ms) * Channels: 100 selectable channels * Modulation: GFSK * Frequency Response: 20–18,000Hz * Total Harmonic Distortion (T.H.D): < 1% * Signal-to-Noise Ratio (S/N): ≥ 75dB * RF Output Power: 10mW * Dynamic Range: 95dB * Operating Distance: 50–100m (open environment) * Frequency Stability: < ±10ppm * Audio Output Level: 10mW * Current Consumption: 160mA * Power Supply: DC 12V / 500mA * Audio Inputs: 3.5mm / 6.35mm / XLR --- **[Bodypack Receiver Specifications]** * Frequency Stability: < ±10ppm * Signal-to-Noise Ratio (S/N): > 95dB * Audio Output Power: 10mW * Current Consumption: 130mA * Battery Type: AA 1.5V × 2 * Audio Output: 3.5mm stereo headphone jack
