SMALL-DIAPHRAGM CONDENSER · HIGH-SPL CARDIOID PICKUP
The 4011A combines cardioid directivity, 40 Hz–20 kHz on-axis response and up to 158 dB SPL peak before clipping with the -20 dB attenuator engaged for compatible high-level recording applications.
| Model / SKU | 4011A / F10001 |
|---|---|
| Product Type | Small-diaphragm condenser microphone |
| Directivity | Cardioid |
| On-Axis Frequency Range | 40 Hz–20 kHz ±2 dB |
| Maximum SPL | 158 dB SPL peak before clipping with attenuator at -20 dB |
| Length / Diameter | 6.89 in / 0.75 in |
| Power | +48V phantom power |
Instrument recording · High-SPL sources · Studio production · Stage capture · Broadcast · Compatible professional recording systems
ELEGAUDIO supports distributors, studios and project buyers. Send quantity, market and intended source application for compatibility and quotation details.
The stated peak is 158 dB SPL before clipping with the attenuator set to -20 dB.
The 4011A is cardioid.
The microphone requires +48V phantom power.
Send your quantity, destination country and recording-source requirements.
REQUEST A QUOTE
