EXTRA-LONG GOOSENECK · CONFERENCE AND CHORUS
The DB-810 combines an extra-long gooseneck, independent vertical frame, balanced output, supercardioid pattern and 48V phantom power for compatible conference-hall speech and chorus applications.
| Model / SKU | DB-810 / L30001 |
|---|---|
| Directivity | Supercardioid |
| Sensitivity | 14.1 mV/Pa (-32 dB ±2 dB) |
| Frequency Range | 50 Hz–20 kHz |
| Electrical Impedance | ≤200Ω |
| Equivalent Noise | 13 dB (A-weighted) |
| Signal-to-Noise Ratio | ≥96 dB |
| Maximum SPL | 118 dB at 1 kHz, distortion ≤1% |
| Power | 48V phantom power |
| Dimensions | Ø22 × 1400 mm |
Large conference halls · Speeches · Chorus · Singing · Lecture halls · Compatible fixed and temporary sound systems
ELEGAUDIO supports distributors, conference integrators, rental companies and project buyers. Send your quantity, destination market and room application for applicable compatibility and quotation information.
The DB-810 uses a supercardioid pattern.
The product information specifies 48V phantom power.
Large conference-hall speech and chorus or singing applications are stated.
Send your quantity, destination country and conference or chorus requirements.
