HY-60CC Power Supply Lavalier Microphone
HY-60CC is a unidirectional powered lavalier microphone with 9.7 × 5.05 mm capsule, 5 m cable and DC 1–10 V operation.
SKU:J20047
PROFESSIONAL AUDIO · B2B SOURCING
HY-60CC is a powered lavalier microphone with unidirectional pickup and a 9.7 × 5.05 mm capsule. Its 5 m cable supports compatible installed or body-worn voice applications when connector and voltage are matched.
HY-60CC is a powered lavalier microphone with unidirectional pickup and a 9.7 × 5.05 mm capsule. Its 5 m cable supports compatible installed or body-worn voice applications when connector and voltage are matched.
| Model | HY-60CC |
| Product type | Lavalier microphone |
| Pickup direction | Unidirectional |
| Capsule size | 9.7 × 5.05 mm |
| Sensitivity | -38 ± 1 dB |
| Frequency response | 100 Hz–10 kHz |
| Output impedance | ≤680 Ω / ≤2.2 kΩ, as stated |
| Working voltage | DC 1–10 V |
| Signal-to-noise ratio | >58 dB |
| Cable length | 5.0 m |
| Connector | Not stated |
| SKU | J20047 |
Relevant to compatible conference, presentation and voice systems. Confirm connector, wiring, working voltage and target input.
Contact ELEGAUDIO for pricing, quantities, availability, packing details and project requirements. Include destination market, quantity and intended application.
What pickup direction is used?
Unidirectional.
How long is the cable?
5.0 m.
What voltage is required?
DC 1–10 V.
Is connector information published?
No. Confirm connector and pin wiring.
