CONDENSER PICKUP · RECORDING AND LIVE AUDIO
Gold-plated Mylar diaphragm, gold-plated three-pin connection, balanced output, low noise and low distortion for studios and live performance.
The DB-74 combines cardioid pickup, 40 Hz–20 kHz response and balanced professional-audio positioning. Confirm power and connection compatibility with the intended system before ordering.
| Model / SKU | DB-74 / F50015 |
|---|---|
| Product Type | Pure condenser speech microphone |
| Directivity | Cardioid |
| Sensitivity | 20 mV/Pa (-32 dB ±2 dB) |
| Frequency Range | 40 Hz–20 kHz |
| Output Impedance | <200Ω |
| Equivalent Noise | 13 dB (A-weighted) |
| Signal-to-Noise Ratio | >96 dB |
| Maximum SPL | 130 dB at 1 kHz, distortion <1% |
| Power | 48V phantom power |
| Dimensions | 22 × 130 mm |
Recording studios · Live performance · Instrument pickup · Speech · Content production · Compatible professional audio systems
ELEGAUDIO supports distributors, importers, studios, rental companies and project buyers. Send your quantity, destination market and intended application for applicable compatibility and quotation information.
The DB-74 uses a cardioid pattern.
The supplied specification lists 48V phantom power.
The stated range is 40 Hz–20 kHz.
Send your quantity, destination country and intended audio application.
